Sekizli
Machine & Crane

Thousands of customers, tons of cargo, millions of hours of operation.

Type	FEM Class	Capacity (ton)	Lifting Height (m)	Hardware B	Drum Length A (mm)	Drum Diameter C (mm)	Wheel Diameter D1 (mm)	Rope Diameter A1 (mm)	Wheel Center E (mm)	Mobile Crane Height H (mm)	Traveling Mechanism Length L (mm)
SV(2,5)M	2m	2,5	6 / 8 / 10	4/1	700 / 700 / 850	160	125	8	1250	350	1150
SV(3,2)M	2m	3,2	6 / 8 / 10	4/1	700 / 700 / 850	160	125	8	1250	350	1150
SV(4)M	2m	4	6 / 8 / 10	4/1	600 / 800 / 900	200	125	10	1250/ 1400/ 1400	400	1360
SV(5)M	2m	5	6 / 8 / 10	4/1	600 / 800 / 900	200	125	10	1250/ 1400/ 1400	400	1360
SV(6,3)M	2m	6,3	6 / 8 / 10	4/1	750 / 750 / 900	240	160	12	1250/ 1250/ 1400	400	1500
SV(8)M	2m	8	6 / 8 / 10	4/1	700 / 850 / 1000	240	160	14	1250/ 1400/ 1500	450	1500
SV(10)M	2m	10	6 / 8 / 10	4/1	700 / 850 / 1000	270	160	14	1250/ 1400/ 1500	450	1500
SV(10)M	2m	12,5	6 / 8 / 10	4/1	700 / 830 / 900	320	160	16	1500/ 1500/ 1750	450	1500
SV(16)M	2m	16	6 / 8 / 10	4/1	700 / 830 / 950	320	160	18	1500/ 1500/ 1750	500	1500
SV(20)M	2m	20	6 / 8 / 10	4/1	700 / 800 / 950	360	200	20	1500/ 1500/ 1750	550	1500
SV(25)M	2m	25	6 / 8 / 10	4/1	750 / 900 / 1050	450	250	22	1500/ 1500/ 1750	650	1600
